ATH200 Temperature and Humidity Monitoring Device

  • ATH-200 temperature sensor
  • best temperature and humidity sensor with digital-meter
  • SENSIRION sensor

ATH200 Temperature and Humidity Monitoring Device with SNMP Support

  • Model: ATH200
  • Temperature Sensor: 2 probes, SENSIRION SHT20
  • Temperature Range: -10°C to +95°C
  • Temperature Accuracy: ±0.1°C
  • Humidity Sensor: 2 probes, SENSIRION SHT20
  • Humidity Range: 5% to 95% RH
  • Humidity Accuracy: ±0.1% RH
  • Processor: Arm® Cortex®-M4 from STMicroelectronics

Overview

The ATH200 is an industrial-grade temperature and humidity monitoring device designed for environments such as data centers, server rooms, and industrial facilities. With high-precision SENSIRION SHT20 sensors and a powerful Arm® Cortex®-M4 processor, it ensures reliable, real-time monitoring. The device offers a versatile range of power input options, multiple connectivity interfaces, and a secure embedded operating system, making it an ideal solution for critical infrastructure monitoring.

Technical Specifications

  • Model: ATH200
  • Temperature & Humidity Sensors:
    • Equipped with 2 simultaneous probes using SENSIRION SHT20 sensors, known for their industrial-grade precision and reliability.
    • Temperature Range: -40°C to +125°C, accuracy: ±0.1°C
    • Humidity Range: 0% to 100% RH, accuracy: ±0.1% RH
  • Processor: Arm® Cortex®-M4 by STMicroelectronics, ensuring fast, real-time data processing.
  • Power Supply Options:
    • Wide DC input voltage range (9V to 36V).
    • Power Consumption: Approximately 1.5W
  • PoE Capability: Supports passive PoE on 12V and 24V lines.
  • Isolated Network Port for better protection.

Applications

  • Data Centers: Protect critical IT infrastructure from environmental hazards such as overheating or high humidity.
  • Industrial Facilities: Monitor environmental conditions in manufacturing plants, warehouses, or other industrial settings.
  • Healthcare & Laboratories: Ensure stable environmental conditions in medical labs and pharmaceutical facilities.

Key Features

  • SENSIRION SHT20 sensors for precise temperature and humidity measurements.
  • Arm® Cortex®-M4 processor for efficient and real-time data processing.
  • Wide DC input range and low power consumption for versatile operation.
  • Passive PoE support for simplified installation and cabling.
  • 5000V isolated network port for enhanced protection and reliability.
  • USB-based probe connections extendable up to 15 meters.
  • 7-segment local display for real-time data visualization.
  • SNMP compatibility for integration with leading network management software.

Specification

Specification Details
Model ATH200
Temperature Sensor 2 probes, SENSIRION SHT20
Temperature Range -10°C to +95°C
Temperature Accuracy ±0.1°C
Humidity Sensor 2 probes, SENSIRION SHT20
Humidity Range 5% to 95% RH
Humidity Accuracy ±0.1% RH
Processor Arm® Cortex®-M4 from STMicroelectronics
Power Input 9V to 36V DC with DC-DC switching
Power Consumption Approx. 1.5W
Passive PoE Support Yes, 12V and 24V (PoE Mode B)
Ethernet Port 10/100 Mbps, 5000V isolation
Probe Connection USB Type-A cable, 1.5m (extendable to 15m)
Local Display 7-segment display for real-time readings
Web Service Built-in web interface for real-time data
SNMP Support SNMPv1, SNMPv2.c (Get, GetNext, Walk commands)
Response Time Less than 1ms
Operating System Secure tamper-proof embedded OS
